Can a digitizer be used as an oscilloscope? Read more...
Latest Oscilloscope News |
100MHz Battery-Portable Oscilloscopes
23 June 2022 - Saelig Company introduced the Micsig STO1004 four-channel battery-powered portable oscilloscope, which offers 100MHz bandwidth, 70Mpts memory, 1GSa/s sampling (single channel), 130,000wfm/s refresh rate, and a 7.5Ah Li battery for extended field use. Improvements over previous Micsig models include an intelligent bidirectional Universal Probe Interface for accommodating and powering smart probes such as those with differential inputs and new joystick control buttons. A smartphone app is also available for remote instrument control.
Isolated Channel PC Oscilloscope
17 June 2022 - Cleverscope introduced the CS548, a 2kV DC isolated channel oscilloscope designed to be useful anywhere isolation and high CMRR are needed - in particular power electronics, including on the high side. Using the CS1200 IsoPod allows a >30kV isolation. The new CS548 features 100 dB CMRR at 50 MHz, Frequency Response Analysis, Component LCR measurement, MSPS streaming to disk for days, high resolution spectra, sophisticated maths, Matlab and Excel live, external sampling clock, Ethernet or USB, Isolated Signal Generator, and mixed signal capture.
10 kV High-Voltage Oscilloscope Probe
15 June 2022 - Cal Test Electronics introduced the CT4432 High-Voltage Oscilloscope Probe. The CT4432 has a 10 kV maximum voltage input rating and is cTUVus listed. The CT4432 High-Voltage Oscilloscope Probe enables the user to safely measure voltage levels up to 10 kV. With the Cal Test Electronics name and certification by cTUVus, the user can be confident this test accessory is both reliable and safe. The CT4432 is covered by a two-year warranty.
SIGLENT launched its first Oscilloscopes with 12-bit vertical Resolution
13 June 2022 - SIGLENT Technologies has introduced a new 12-bit oscilloscope series. Compared to 8-bit ADCs, 12-bit systems have 16x higher vertical resolution which provides significantly lower quantization error. This improvement in resolution is valuable when analyzing the smallest signal details, and is especially useful when the zoom function is used. The analog-to-digital converters have a maximum sampling rate of 2 GS/s and all models in the series come with 4 analog input channels. All oscilloscopes are equipped with two AD converters and 2 x 200 Mpt acquisition memory. With four activated channels, this results in a minimum sampling rate of 1GS/s and a memory depth of 100 MPkt at each channel.
Rohde & Schwarz enhances its R&S RTP High-Performance Oscilloscope
10 June 2022 - Rohde & Schwarz introduced the new generation of R&S RTP high-performance oscilloscopes, which combine high-class signal integrity measurements with the fastest possible acquisition for real-time analysis. The new models come with a bigger and brighter 13.3” full HD touchscreen and a fully redesigned front panel. Users can take advantage of the crisp 16:9 screen format, which displays waveforms while allowing settings to be altered and changed quickly. The intuitive front panel increases productivity with fast, direct access to primary instrument settings.
Tektronix launched 2 Series Mixed Signal Oscilloscopes
08 June 2022 - Tektronix unveiled the 2 Series Mixed Signal Oscilloscope (MSO). The new 2 Series MSO can go seamlessly from the bench to the field and back, enabling workflows previously unimagined on a scope. It is the first portable oscilloscope to offer benchtop performance and the award-winning Tektronix user interface. Weighing less than 1.8kgs and 38mm thin, the 2 Series MSO can fit into a small backpack, delivering unmatched performance and portability.
Simplified System Integration Debugging with USB Type-C Test Coupon Fixtures
07 June 2022 – Teledyne LeCroy announced USB Type-C High-speed and Sideband Test Coupon Fixtures that provide the industry’s first oscilloscope solution for high-speed probing and analysis of an active data link at the USB Type-C connector. Additional connection to a Teledyne LeCroy protocol analyzer provides complete debug capability of any USB Type-C link negotiation failure.
Oscilloscope Basics |
A Comparison between Oscilloscopes and Spectrum Analyzers
Whether it is for a land survey searching for minerals on Earth, or for a space exploration in search of alien life forms, the analysis of any signal boils down to looking at its time and frequency information. While an oscilloscope displays a signal with respect to time, a spectrum analyzer shows it with respect to frequency. Both of these tools are very important in any signal analysis application. This article explains the difference between oscilloscope and spectrum analyzer using examples.
Oscilloscope Background |
A simple method to verify the bandwidth of your probe
In oscilloscopes or oscilloscope probes, bandwidth is a measure of the width of a range of frequencies measured in Hertz. Specifically, bandwidth is specified as the frequency at which a sinusoidal input signal is attenuated to 70.7 percent of its original amplitude, also known as the -3 dB point. Most oscilloscope companies design the scope/probe response to be as flat as possible throughout its specified frequency range, and most customers simply rely on the specified bandwidth of the oscilloscope or oscilloscope probes, wondering if they are indeed getting the bandwidth performance at the probe tip. Now you can use these step-by-step instructions to simply measure and verify the bandwidth of your probe with an oscilloscope you may already have.
