TLC PCIeInterposer27 June 2022 – Teledyne LeCroy announced availability of a PCI Express 5.0 Open Compute Project (OCP) Network Interface Card (NIC) 3.0 interposer that works in combination with Teledyne LeCroy’s Summit family of PCI Express 5.0 protocol analyzers. The new OCP interposer allows engineers to test product designs that incorporate OCP NIC 3.0 with PCIe 5.0, NVM Express (NVMe) or Compute Express Link (CXL) technologies. The PCIe 5.0 OCP interposer joins the list of CrossSync PHY enabled interposers, allowing users to debug enhanced power management and link training equalization through correlated and time aligned physical and protocol layer views.

Micsig STO100423 June 2022 - Saelig Company introduced the Micsig STO1004 four-channel battery-powered portable oscilloscope, which offers 100MHz bandwidth, 70Mpts memory, 1GSa/s sampling (single channel), 130,000wfm/s refresh rate, and a 7.5Ah Li battery for extended field use. Improvements over previous Micsig models include an intelligent bidirectional Universal Probe Interface for accommodating and powering smart probes such as those with differential inputs and new joystick control buttons. A smartphone app is also available for remote instrument control.

CS CS54817 June 2022 - Cleverscope introduced the CS548, a 2kV DC isolated channel oscilloscope designed to be useful anywhere isolation and high CMRR are needed - in particular power electronics, including on the high side. Using the CS1200 IsoPod allows a >30kV isolation. The new CS548 features 100 dB CMRR at 50 MHz, Frequency Response Analysis, Component LCR measurement, MSPS streaming to disk for days, high resolution spectra, sophisticated maths, Matlab and Excel live, external sampling clock, Ethernet or USB, Isolated Signal Generator, and mixed signal capture.

Caltech CT4432 IsoView15 June 2022 - Cal Test Electronics introduced the CT4432 High-Voltage Oscilloscope Probe. The CT4432 has a 10 kV maximum voltage input rating and is cTUVus listed. The CT4432 High-Voltage Oscilloscope Probe enables the user to safely measure voltage levels up to 10 kV. With the Cal Test Electronics name and certification by cTUVus, the user can be confident this test accessory is both reliable and safe. The CT4432 is covered by a two-year warranty.

Siglent SDS2000X13 June 2022 - SIGLENT Technologies has introduced a new 12-bit oscilloscope series. Compared to 8-bit ADCs, 12-bit systems have 16x higher vertical resolution which provides significantly lower quantization error. This improvement in resolution is valuable when analyzing the smallest signal details, and is especially useful when the zoom function is used. The analog-to-digital converters have a maximum sampling rate of 2 GS/s and all models in the series come with 4 analog input channels. All oscilloscopes are equipped with two AD converters and 2 x 200 Mpt acquisition memory. With four activated channels, this results in a minimum sampling rate of 1GS/s and a memory depth of 100 MPkt at each channel.

RS RTP210 June 2022 - Rohde & Schwarz introduced the new generation of R&S RTP high-performance oscilloscopes, which combine high-class signal integrity measurements with the fastest possible acquisition for real-time analysis. The new models come with a bigger and brighter 13.3” full HD touchscreen and a fully redesigned front panel. Users can take advantage of the crisp 16:9 screen format, which displays waveforms while allowing settings to be altered and changed quickly. The intuitive front panel increases productivity with fast, direct access to primary instrument settings.

Tek Series208 June 2022 - Tektronix unveiled the 2 Series Mixed Signal Oscilloscope (MSO). The new 2 Series MSO can go seamlessly from the bench to the field and back, enabling workflows previously unimagined on a scope. It is the first portable oscilloscope to offer benchtop performance and the award-winning Tektronix user interface. Weighing less than 1.8kgs and 38mm thin, the 2 Series MSO can fit into a small backpack, delivering unmatched performance and portability.

TLC USB C Connector07 June 2022 – Teledyne LeCroy announced USB Type-C High-speed and Sideband Test Coupon Fixtures that provide the industry’s first oscilloscope solution for high-speed probing and analysis of an active data link at the USB Type-C connector. Additional connection to a Teledyne LeCroy protocol analyzer provides complete debug capability of any USB Type-C link negotiation failure.

TLC wavemaster8zi b16 May 2022 - Teledyne LeCroy annouced a new MultiGBASE-T1 Automotive Ethernet standard compliance test solution. QPHY-MultiGBase-T1 is a software package which automates compliance testing and validation of 2.5G, 5G and 10G Automotive Ethernet, as is described in the MultGBase-T1 (IEEE 802.3ch) specification. Detailed connection diagrams ensure the proper setup and provide information about the required test pattern for each test. Upon completion of the test session, results are automatically compiled into a comprehensive report including screenshots.

Rigol MSO800003 May 2022 - Rigol improved the MSO8000 high-performance digital oscilloscope family in order to make its use and operability even more pleasant and versatile. The MSO8000 series is part of the UltraVision II oscilloscope portfolio, which also includes the proprietary ASIC chipset. Improvements and new functions are available e.g. in the areas of web control, touch display, acquisition memory and coding options.
