Latest Oscilloscope News |
High Voltage Differential Probe for up to 7000 Vpk
31 May 2024 - Micsig released the latest model of its high-voltage differential probe - the DP7000. This new model, building on the performance of the original MDP series, has further increased the test voltage from the original 3000 Vpk to 7000 Vpk, bringing a more powerful measurement tool to the field of electronic testing.
Compact Oscilloscope for Rack Mount
15 May 2024 - Rohde & Schwarz extends its portfolio with a 2U high oscilloscope/digitizer tailored for rack mount and other applications where a low-profile form factor is critical. The new MXO 5C series is the company’s first oscilloscope without an integrated display. It delivers the same performance as the previously introduced MXO 5 series, but with a fourth of the vertical height.
Batronix develops its own Oscilloscope
29 April 2024 - German measurement technology distributor Batronix has developed its own 4-channel oscilloscope with up to 350 MHz bandwidth, the Magnova BMO350. The oscilloscope is available with a bandwidth of 100, 200 or 350 MHz and features a 1.6 GSa/s sampling rate, 12-bit A/D converter, 320 Mpts memory depth and 39.6 cm touch display with full HD resolution (1920x1080 pixels). It can be upgraded to an MSO with 16 channel logic analyser and 1 channel 90 MHz function generator. Batronix has broken new ground in the development of the Magnova. It is not just another oscilloscope, everything has been redesigned from the ground up.
Spectrum Analysis of up to 8 simultaneous Signals
26 April 2024 - Tektronix released its SignalVu Spectrum Analyzer Software, Version 5.4, for multi-channel modulation analysis of up to eight signals in parallel. Engineers can use this software to turn their existing oscilloscope into a comprehensive wireless system tester, instead of investing in a dedicated tester such as a vector signal analyzer. It is particularly valuable for applications requiring time-domain analysis with RF measurements. The package runs on Tektronix 5 Series MSO, 6 Series MSO or DPO70000 oscilloscopes.
5-in-1 Programmable Oscilloscopes
25 March 2024 - Saelig Company introduced the GW Instek MPO-2000 Series Multifunction Programmable Oscilloscopes. These instruments combine, in one space-saving box, a full-featured oscilloscope, a spectrum analyzer, an arbitrary waveform generator, a digital multimeter, and a 2-channel 20VDC power supply. In addition to its five-in-one multi-functional architecture, it features Python script functionality into the MPO-2000, enabling users to create a small, low-cost automated test system without an external controlling PC. Python is widely used in scientific computing, data analysis, web development, artificial intelligence, and other fields since it is easy to learn and use.
Decode, Trigger & Search Support for the CAN XL Protocol
20 March 2024 - Tektronix announced the release of the Tektronix CAN XL (Controller Area Network Extended Length) protocol decoder, enabling engineers incorporating the latest generation of CAN communications, and helping Tektronix customers compete in today’s fast-changing technology landscape. With the ability to decode signals representing data packets transmitted using CAN XL frames in a CAN network, the Tektronix CAN XL protocol decoder runs on today’s 4, 5, 6 Series MSO Oscilloscopes and also offers critical features such as error detection, analysis and debugging of timing and protocol headers.
Oscilloscope Days Event in April
18 March 2024 - Rohde & Schwarz announced that its popular Oscilloscope Days educational event will return for two days, April 17 to 18, 2024. Experts from Rohde & Schwarz and partner companies will present the latest updates on fundamentals and test features for engineers using next-generation oscilloscopes, covering topics such as power electronics and EMC, as well as signal and power integrity.
- Three new 12-Bit Oscilloscopes Series
- High-Performance Oscilloscope optimized for Speed
- Pico Technology released PicoScope 7
- Oscilloscope Probes for Bandwidths up to 52 GHz
- High-Speed Communication Analyzer
- 500 MHz High Resolution Oscilloscopes with 14” Touchscreen
- Innovative Oscilloscope Training and Demo Board
Page 7 of 78
Oscilloscope Basics |
Oscilloscope Probes – Vital Link in the Measurement Chain
Signal measurement results can only be as accurate as the test and measurement tools in use. As clock rates and edge speeds of today’s electronic circuits increase, probing becomes a critical piece of the measurement system – the component that comes in direct contact with your circuit. This article looks at voltage probing considerations for embedded system and digital design debugging applications.
Oscilloscope Background |
A simple method to verify the bandwidth of your probe
In oscilloscopes or oscilloscope probes, bandwidth is a measure of the width of a range of frequencies measured in Hertz. Specifically, bandwidth is specified as the frequency at which a sinusoidal input signal is attenuated to 70.7 percent of its original amplitude, also known as the -3 dB point. Most oscilloscope companies design the scope/probe response to be as flat as possible throughout its specified frequency range, and most customers simply rely on the specified bandwidth of the oscilloscope or oscilloscope probes, wondering if they are indeed getting the bandwidth performance at the probe tip. Now you can use these step-by-step instructions to simply measure and verify the bandwidth of your probe with an oscilloscope you may already have.
